Soiltech Supreme Rotavator – Affordable, Heavy-Duty Tractor Rotavator Specifications in India
Description
Discover the Soiltech Supreme Rotavator price in India*, ideal for paddy, wheat, vegetables. Best Rotavator for farming with durable blades, 30–80 HP compatibility. Choose with TractorXpert.
Key Features and Technology
- Heavy-Duty Construction: Robust frame and gearbox support continuous use in tough soils.
- Specialized Rotor & Blade Design: High-hardness blades for deeper cutting and longer life.
- Adjustable Drive & Speed: Multiple drive options to match tractor power compatibility and field conditions.
- Moisture-Retaining Action: Increases soil porosity for better seed germination.
Technical Specifications and Model Variants
Soiltech Supreme Series Rotavator Specifications
| Specification | HD-160 | HD-175 | HD-185 | HD-210 | HD-235 | HD-260 | HD-285 |
| Series Name | Supreme | Supreme | Supreme | Supreme Plus | Supreme Plus | Supreme Plus | Supreme Plus |
| Working Size (ft) | 5′ | 5.5′ | 6′ | 7′ | 8′ | 9′ | 10′ |
| Tractor Power (HP) | 35–45 | 40–50 | 40–50 | 45–55 | 50–60 | 60–70 | 70–80 |
| Overall Length (mm) | 1,755 | 1,929 | 2,000 | 2,245 | 2,490 | 2,977 | 3,198 |
| Overall Width (mm) | 950 | 950 | 950 | 950 | 950 | 950 | 950 |
| Tilling Width (mm/inch) | 1,455 / 57″ | 1,629 / 64″ | 1,700 / 67″ | 1,945 / 76″ | 2,190 / 86″ | 2,677 / 105″ | 2,898 / 114″ |
| Overall Height (mm) | 1,080 | 1,080 | 1,080 | 1,080 | 1,080 | 1,080 | 1,080 |
| 3-Point Hitch Type | CAT-II | CAT-II | CAT-II | CAT-II | CAT-II | CAT-II | CAT-II |
| Frame Offset (mm/inch) | 62 / 0.5″ | 62 / 0.5″ | 62 / 0.5″ | 24.5 / 1″ | 12.75 / 0.5″ | 8 / 0.3″ | 5 / 0.2″ |
| Number of Blades (L-80×7) | 36 | 42 | 42/48 | 48/54 | 54/60 | 66 | 72 |
| Main Gearbox Type | Multi-Speed (13×23) | Multi-Speed (13×23) | Multi-Speed (13×23) | Multi-Speed (13×23) | Multi-Speed (13×23) | Multi-Speed (13×23) | Multi-Speed (13×23) |
| Side Transmission Type | Gear (20-42-28) | Gear (20-42-28) | Gear (20-42-28) | Gear (20-42-28) | Gear (20-42-28) | Gear (20-42-28) | Gear (20-42-28) |
| Max. Working Depth (mm/inch) | 148 / 5.5″ | 148 / 5.5″ | 148 / 5.5″ | 148 / 5.5″ | 148 / 5.5″ | 148 / 5.5″ | 148 / 5.5″ |
| Rotor Tube Diameter (mm) | 89 | 89 | 89 | 89 | 89 | 89 | 89 |
| Rotor Swing Diameter (mm) | 470 | 470 | 470 | 470 | 470 | 470 | 470 |
| Driveline Safety Device | Shear Bolt | Shear Bolt | Shear Bolt | Shear Bolt | Shear Bolt | Shear Bolt | Shear Bolt |
| Weight (kg) | 455 | 468 | 475 | 515 | 535 | 645 | 675 |
Rotor RPM Chart (Standard Gear Pair 16–19)
| Input PTO RPM | Reduction Gear 1 | Reduction Gear 2 | Rotor Shaft RPM |
| 540 | 16 | 19 | 184 |
| 540 | 17 | 18 | 206 |
| 540 | 18 | 17 | 231 |
| 540 | 15 | 20 | 164 |
| 540 | 20 | 15 | 291 |
| 1,000 | 13 | 23 | 239 |
| 1,000 | 22 | 13 | 683 |
Agricultural Benefits and Applications
Enhanced Farming Efficiency
- Fuel Savings & Time Reduction: Faster soil preparation reduces tractor run-time.
- Improved Soil Health: Better aeration and moisture retention support root growth.
- Reduced Labor Cost: Mechanization replaces manual tilling.
Versatile Crop Applications
- Ideal Rotavator for farming paddy, wheat, sugarcane, cotton, maize, vegetables, and more.
Performance Specifications
Depth and Width Capabilities
- Working Width: 1.2 m, 1.5 m, 1.8 m model variants
- Cultivation Depth: Up to 16 cm per pass
Pricing and Value Proposition
Soiltech Supreme Rotavator delivers a balance of affordable Rotavator price and premium build quality. Each variant offers value-for-money farm implement advantages—sturdy design, long-life blades, and versatile use.
Maintenance and Care
- Blade Care: Regular sharpening and inspection for optimal performance.
- Lubrication: Grease gearbox and rotor bearings after every 50 hours.
- Servicing: Annual check of gearbox oil and seals to prevent wear.
Longevity Factors
- Durability: High-tensile steel frame resists bending.
- Wear & Tear: Hardened blade edges reduce frequent replacements.
- Gearbox Strength: Industrial-grade gears for heavy loads.
FAQs
What tractor horsepower (HP) is required for Soiltech Supreme Rotavator?
Soiltech Supreme supports tractors from 30 HP up to 80 HP, depending on model variant.
Which types of blades are available in Soiltech Supreme, and what do they do?
Supreme offers L-type blades for vegetables, S-type for paddy/wheat, and Z-type for heavy soil cultivation.
What is the working width of the Soiltech Supreme Rotavator?
Working widths are 1.2 m, 1.5 m, and 1.8 m.
How deep can the Soiltech Supreme Rotavator cultivate in a single pass?
Up to 16 cm depth, adjustable per field conditions.
How important is blade hardness and quality in Soiltech Supreme?
High blade hardness ensures longer life, precise cutting, and consistent performance—crucial for bad soil.
Are Soiltech Supreme Rotavators compatible with all tractor brands and models in India?
Yes, they mount on standard three-point linkage and fit any tractor within the specified HP range.
What about maintenance and warranty in Soiltech Supreme?
Routine blade sharpening, gearbox lubrication, and annual servicing keep your Rotavator running. Manufacturer warranty covers one year on gearbox and frame.
How TractorXpert Helps Farmers Choose
TractorXpert simplifies farm mechanization in India by comparing Tractor Rotavator specifications, Rotavator price in India, model features, and agricultural benefits. Whether you need a heavy-duty Rotavator for paddy fields or an affordable Rotavator price* for small plots, TractorXpert guides you to the best Rotavator for farming.
