Soiltech Harrow (ST Series: 5 FT, 6 FT, 7 FT, 8 FT)
{{ galleryProps.activeIndex + 1 }}/1
Description
- About Product
Brand: Soiltech
Model Name: Harrow (ST Series: 5 FT, 6 FT, 7 FT,…
- About Product
Brand: Soiltech
Model Name: Harrow (ST Series: 5 FT, 6 FT, 7 FT, 8 FT)
Implement Type: Spike Tooth Harrow
Category: Secondary Tillage / Soil Preparation
Compatible Tractor Power: 40–60 HP
Price Range:*: Contact TractorXpert for price*
- Key Specification and Technology – Soiltech Harrow Variants
| Variant (Size) | Tractor Power (HP) | Hitch Type | Overall Width (mm) | Working Width (mm) | Tillage Depth (in/cm) | Gearbox | Rotor Speed (RPM) | Number of Blades | Approx. Weight (kg) |
| 5 FT (ST) | 40–45 | Pyramid hitch | 1 750 | 1 500 | 5–7 in/12–18 cm | 15:24 MS 4-speed | 180–259 | 36 | 394 |
| 6 FT (ST+) | 40–50 | Pyramid hitch | 2 000 | 1 750 | 5–7 in/12–18 cm | 15:24 MS 4-speed | 180–259 | 42 | 421 |
| 7 FT (ST) | 50–55 | Pyramid hitch | 2 250 | 2 000 | 5–7 in/12–18 cm | 15:24 MS 4-speed | 180–259 | 48 | 454 |
| 8 FT (ST+) | 55–60 | Pyramid hitch | 2 500 | 2 250 | 5–7 in/12–18 cm | 15:24 MS 4-speed | 180–259 | 54 | 505 |
- Technical Specifications – Soiltech Harrow
- Soil Compatibility: Light, medium, heavy soils; ideal for loamy and stony fields
- Field Efficiency: Covers up to 1 ha/hr at 6–8 km/hr
- Fuel Consumption Impact: Reduces tractor load by up to 10% via efficient design
- Build Quality: MS–steel frame with pyramid hitch for stability
- Bearings & Seals: Sealed bearings for dust and moisture protection
- Maintenance: Grease gearbox and rotor bearings every 50 hrs; inspect blades every 100 hrs
- Spare Parts: Available through dealer network; low-cost blade replacements
- Warranty: 12 months or 1 000 hrs; authorized service centers nationwide
- Weather Suitability: Operates effectively in wet and dry field conditions
- Crop Compatibility: Suitable for pre-sowing of cereals, pulses, vegetables
- Agricultural Benefits and Applications
- Primary Tillage: Light soil breaking and residue incorporation
- Secondary Tillage: Fine seedbed refinement and leveling
- Weed Control: Uproots weeds and mixes crop residues evenly
- Soil Structure: Improves soil porosity and reduces compaction
- Enhanced Farming Efficiency
- Time-Saving: Single-pass operations reduce field prep time
- Fuel Efficiency: Up to 10% fuel savings over conventional harrows
- Labor Reduction: Easy hitch-up and simple depth adjustment
- Productivity: Uniform blade action ensures consistent coverage
- Versatile Crop Applications
Suitable for:
- Cereals: Wheat, barley, oats, rice
- Cash Crops: Cotton, sugarcane, maize, sunflower
- Pulses: Chickpea, lentils, pigeon pea
- Vegetables: Potato, onion, tomato
- Orchards & Plantations: Vineyards, nurseries
- Performance Specifications
- Operating Speed: 6–8 km/hr
- Ground Pressure Distribution: Even blade loading prevents rutting
- Penetration Capability: 12–18 cm depth in varied soils
- Finish Quality: Creates fine tilth and level seedbed
- Farmer Decision Support
Farm Size Recommendations:
- Small farms (< 5 acres): 5 FT variant
- Medium farms (5–25 acres): 6–7 FT variants
- Large farms (> 25 acres): 8 FT variant
Soil-Specific Advice:
- Light soils: 5–6 FT, shallow depth
- Medium soils: 6–7 FT, moderate depth
- Heavy soils: 7–8 FT, full 18 cm depth
Budget Categories:
- Economy: 5 FT basic model*
- Mid-Range: 6–7 FT models*
- Premium: 8 FT wide coverage model*
ROI & Financing:
- Payback in 1–2 seasons through reduced fuel and labor
- Implement loans and government mechanization subsidies available
- Maintenance and Care
- Blade Maintenance: Inspect and rotate blades every 100 hrs; replace when worn
- Gearbox Care: Check oil level monthly; service every 500 hrs
- Frame Inspection: Tighten bolts and check welds annually; apply rust-preventive paint
- Storage: Store under shelter; clean and cover to prevent corrosion
- Pre-Operation Checklist: Verify hitch pins, gearbox oil, blade tightness
- Longevity Factors
- Material Quality: MS-steel frame and blades heat-treated for durability
- Wear Resistance: Blade life expectancy of 600–800 hrs
- Structural Durability: Robust pyramid hitch design resists stress
- Service Life: 5–7 years with regular maintenance
FAQs – Soiltech Harrow
What HP is required for Soiltech Harrow?
40–60 HP tractors.
What harrow types are available and what do they do?
Spike-tooth blades for soil breaking, leveling, and residue mixing.
What is the working width and depth capacity?
Widths range from 1.5–2.25 m; depth of 12–18 cm.
How does it help seedbed preparation?
Creates a fine, level tilth with uniform blade action.
Why is blade quality important?
Heat-treated blades resist wear and maintain cutting efficiency.
Is it compatible with all tractor brands?
Yes, fits standard pyramid hitch on Indian tractors.
What about depth control?
Simple skid plate adjustment sets tillage depth precisely.
How does it compare to disc harrows and cultivators?
Lower draft than discs, finer finish than cultivators at reduced fuel use.
What maintenance schedule is recommended?
Grease gearbox and bearings every 50 hrs; blade checks every 100 hrs.
What warranty and service support are available?
12 months/1 000 hrs warranty; service through authorized dealers.
TractorXpert helps farmers compare soil preparation implements—analyzing models, prices*, features, and benefits—to choose the right harrow, save costs, improve seedbed quality, and boost farm productivity.
Product General Information
Brand Name:
Soiltech
Model Name:
Harrow (ST Series: 5 FT, 6 FT, 7 FT, 8 FT)
Implement Type:
Harrow
Category:
Tillage
Compatible Tractor Power:
40–60 HP
Engine
Transmission
Implement Type:
Harrow
Category:
Tillage
Power Take off
Dimension & Weight
Hydraulics
Wheels
Cutting Mechanism
Reel
Threshing and Cleaning
Capacity
Other Information
