Soil Master Disc Harrow (DH Series)
{{ galleryProps.activeIndex + 1 }}/1
Description
- About Product
Soil Master Disc Harrow price* in India, specifications, working width, depth & disc details.…
- About Product
Soil Master Disc Harrow price* in India, specifications, working width, depth & disc details. Find the best tractor harrow implements on TractorXpert.
2.Key Specification and Technology – Soil Master Disc Harrow
- Type of Harrow: Disc Harrow
- Number of Discs: 20 (common models, split gang)
- Working Width: Approx. 1.8–2.5 m (model-dependent)
- Working Depth: 100–180 mm (4–7 in; field adjustable)
- Disc Diameter: 24″ × 5 mm (610 mm, boron steel)
- Disc Spacing: 225 mm
- Overall Dimensions: Model-dependent; compact design for easy transport
- Weight: 350–700 kg (varies by model)
- Tractor Power Requirement: 21–30 HP (compact), up to 75 HP (heavy-duty)
- Mounting Type: Three-point linkage (CAT I & II), trailed versions available
- Frame Material: 6 mm heavy-duty square tube frame
- Gang Arrangement: Split gang, adjustable disc angle
- Gang Angle Adjustment: Easily adjustable (mechanical lever)
- Technical Specifications – Soil Master Disc Harrow
- Soil Compatibility: Light, medium, and clay soils; effective even in heavy residue fields
- Field Efficiency: Up to 1.2 ha/hr in favorable conditions
- Fuel Impact: Efficient design reduces fuel use by up to 10% over manual tillage
- Build Quality: Boron steel discs, robust frame, S.G. iron bearing hubs
- Bearings & Seals: Sealed heavy-duty hubs (8 nos., S.G. IRON 500/7)
- Maintenance: Grease hubs every 50 hrs; inspect discs and bolts quarterly
- Spare Parts: Widely available; cost-efficient replacement discs and bearings
- Warranty: 12 months or 1,000 hrs (model-dependent)
- Weather Suitability: Wet and dry field operations
- Crop Compatibility: Suitable for seasonal and year-round farming
- Agricultural Benefits and Applications of Soil Master Disc Harrow
- Primary Tillage: Breaks hard clods, cuts and mixes crop residue, buries weeds
- Secondary Tillage: Creates fine seedbed, improves granulation for sowing
- Weed Control: Cuts existing weeds, covers roots for better suppression
- Soil Structure: Promotes better aeration and water infiltration, reduces compaction
- Enhanced Farming Efficiency through Soil Master Disc Harrow
- Time-Saving: One-pass operation preps soil faster than traditional tools
- Fuel Efficiency: Fewer passes, less drag mean lower tractor fuel use
- Labor Reduction: Easy towing, no manual tillage
- Productivity Gains: Uniform seedbed boosts crop emergence
- Versatile Crop Applications through Soil Master Disc Harrow
- Cereal Crops: Wheat, barley, oats, rice
- Cash Crops: Cotton, sugarcane, maize, sunflower
- Pulses: Chickpea, lentils, pigeon pea
- Vegetables: Potato, onion, tomato
- Orchard/Plantations: Vineyards, fruit orchards
- Performance Specifications of Soil Master Disc Harrow
- Operating Speed: 7–15 km/hr (field, model and soil dependent)
- Ground Pressure: Uniform, resists formation of compacted layers
- Penetration Capability: Excellent in medium and light, moderate in hard clay
- Finish Quality: Fine, even seedbed with residue mixed below surface
- Farmer Decision Support
Farm Size Recommendations:
- Small farms (<5 acres): Compact disc harrow (21–30 HP models)*
- Medium farms (5–25 acres): Standard 20-disc (40–55 HP models)*
- Large farms (>25 acres): Heavy-duty 24–28 disc (60–75 HP)*
Soil-specific Recommendations:
- Light soil: 20-disc, front notched disc, medium depth
- Medium soil: 20–24 disc, heavier frame for deeper tillage
- Heavy clay: Large disc diameter, extra gang weight, deeper tillage
Budget Categories:
- Economy: Light/compact models*
- Mid-range: Standard 20-disc with adjustable angle*
- Premium: Heavy-duty boron steel disc, reinforced frame*
ROI & Financing:
- Payback in 1–2 seasons via saved labor and fuel*
- Government subsidies and implement loans available
- Maintenance and Care of Soil Master Disc Harrow
- Disc Maintenance: Inspect/sharpen quarterly, replace when worn
- Bearing Lubrication: Grease every 50–100 hrs
- Frame Care: Tighten bolts, check for rust, apply anti-corrosive paint annually
- Storage: Covered dry place, clean after use
- Pre-op Checklist: Check gang bolts, linkage, bearing condition
- Longevity Factors of Soil Master Disc Harrow
- Material Quality: Boron steel discs, heat-treated for durability
- Wear Resistance: 800–1,000 hr disc lifespan
- Frame Strength: 6 mm square tube, heavy-duty central bar
- Component Replaceability: Modular parts, easy in-field service
FAQs Section – Soil Master Disc Harrow
What tractor horsepower (HP) is required for Soil Master Disc Harrow?
21–30 HP for compact; up to 75 HP for larger models.
What types of harrows are available and what do they do?
Disc harrow (split gang) breaks clods, incorporates residue, and levels field.
What is the working width and depth capacity?
Working width approx. 1.8–2.5 m; depth 100–180 mm (adjustable).
How does Soil Master Disc Harrow help in seedbed preparation?
It pulverizes clods, creates a fine tilth, and mixes residues evenly for superior seedbed.
Why is disc and frame quality important?
Boron steel discs and heavy-duty frames increase durability and tillage efficiency.
Is Soil Master Disc Harrow compatible with all tractor brands?
Yes, it fits standard CAT I & II linkage; trailed versions are also available.
What about gang angle and depth control?
Quick-adjust split gang angle; mechanical lever for depth.
How does it compare to cultivators and rotavators?
Disc harrows are faster than cultivators; less soil inversion than rotavators but better in residue handling.
What maintenance schedule to follow?
Grease bearings every 50 hrs, check discs/bolts quarterly, inspect hubs and frame annually.
What warranty and after-sales support is available?
12 months/1,000 hrs warranty; spare parts and service support through authorized dealers.
TractorXpert simplifies finding the best harrow price in India by helping farmers compare disc harrow for farming based on price*, specifications, durability, and field performance. With TractorXpert, farmers can confidently select the right agricultural implements for soil preparation, improving yield, saving costs, and maximizing productivity in every season.
Product General Information
Brand Name:
Soil Master
Model Name:
Disc Harrow (DH Series)
Implement Type:
Harrow
Category:
Tillage
Compatible Tractor Power:
21–30 HP (compact), 40–75 HP (full-size models)
Engine
Transmission
Implement Type:
Harrow
Category:
Tillage
Power Take off
Dimension & Weight
Hydraulics
Wheels
Cutting Mechanism
Reel
Threshing and Cleaning
Capacity
Other Information
₹ 340000
₹ 1L
₹ 25L
6.5 %
6%
26%
12
12
60
