Mitra Agro Equipments Bullet Series (3PL, 575, 616)
{{ galleryProps.activeIndex + 1 }}/1
Description
- About Product
| Attribute | Details |
| Brand | Mitra Agro Equipments |
- About Product
| Attribute | Details |
| Brand | Mitra Agro Equipments |
| Model Name | Bullet Series (3PL, 575, 616) |
| Implement Type | Air Blast Sprayer / Orchard Sprayer |
| Category | Crop Protection / Plant Protection |
| Compatible Tractor Power | 18–24 HP and above |
| Price Range* | Contact TractorXpert for Price* |
- Key Specification and Technology – Mitra Bullet Series
| Specification | BULLET 3PL | BULLET 575 | BULLET 616 |
| Sprayer Type | Air Assisted Sprayer | Air Assisted Sprayer | Air Assisted Sprayer |
| Tank Capacity | 200 L | 200 L | 200 L |
| Pump Type | Diaphragm Pump | Diaphragm Pump | Diaphragm Pump |
| Pump Capacity | 55 LPM | 55 LPM | 65 LPM |
| Maximum Working Pressure | Up to 40 bar | Up to 40 bar | Up to 40 bar |
| Fan Size | 550 mm | 575 mm | 616 mm |
| Fan Type | Rear Air Conveyor with Stainless Steel Shell | Same | Same |
| Number of Nozzles | 10 | 12 | 12 |
| Nozzle Types | High-Quality Brass Nozzles | Same | Same |
| Air Output | 24 m/sec | 26 m/sec | 32 m/sec |
| Overall Dimensions (L×W×H) | Compact Design | Standard | Standard |
| Weight (Unladen) | Lightweight | Medium | Medium |
| Tractor Power Requirement | 18 HP and above | 24 HP and above | 24 HP and above |
| Mounting Type | 3-Point Linkage / Customized Mounting Plates | Customized Mounting Plates | Customized Mounting Plates |
| Drive System | PTO Driven | PTO Driven | PTO Driven |
| PTO Speed Requirement | 540 RPM Standard | 540 RPM Standard | 540 RPM Standard |
| Tank Material | High-Density Polyethylene | Same | Same |
| Gearbox | 2-Speed + 1 Neutral Gearbox | Same | Same |
| Safety Devices | Pressure Relief Valve (40 bar), Rear Bumper | Same | Same |
- Technical Specifications – Mitra Bullet Series
| Parameter | Specification |
| Application Rate Capacity | 100–400 L/ha |
| Field Coverage Efficiency | Up to 5–7 ha/day |
| Height Adjustment | Hydraulic height adjustment (Bullet 3PL) for muddy conditions and canopy height |
| Pump Working Pressure | Up to 40 bar with automatic pressure relief valve |
| Agitation System | Mechanical Agitator for constant chemical concentration |
| Filtration System | Suction Filter (Primary), Brass Line Filter (Secondary), Nozzle Filters |
| Control System | Manual 5-Mode Controller with Two-Way Nozzles |
| Operating Speed Range | 3–8 km/hr |
| Chemical Compatibility | Pesticides, Fungicides, Insecticides, Fertilizers |
| Weather Suitability | Wind ≤ 7 m/s, Temperature 5–40 °C |
| Maintenance Intervals | Regular maintenance as per manufacturer guidelines |
| Spare Parts Availability | Pan-India Dealer Network |
| Warranty & Service Support | 1 Year Warranty, Doorstep Service |
| Water Savings | Up to 90% water savings (10 times less water consumption) |
| Special Features | Inlet vanes, air recovery duct for perfect air balancing, basket mixture for dry powder mixing, rear-side water level indicator |
- Agricultural Benefits and Applications of Mitra Bullet
The Mitra Bullet delivers perfect air balancing with highest air output and low power consumption for effective pest control, disease prevention, and crop protection in orchards and vineyards. The rear air conveyor system with stainless steel construction ensures uniform coverage and reduced chemical drift.
- Enhanced Farming Efficiency through Mitra Bullet
The Bullet Series covers up to 5–7 hectares daily while using 90% less water than conventional sprayers. Proven chemical savings and labor savings reduce operational costs. The 2-speed + 1 neutral gearbox allows low-speed operation during flowering to prevent flower drop, maximizing application accuracy.
- Versatile Crop Applications through Mitra Bullet
Horticultural Crops: Grapes, pomegranates, oranges, mangoes, guava, custard apples
Orchard Crops: All types of orchard crops
Vineyard Applications: Low-spacing vineyards with constrained turning radius
Special Applications: Spraying and dipping applications, fungicide application, insecticide spraying, fertilizer application
- Performance Specifications of Mitra Bullet
Achieves uniform coverage with high-velocity air stream (24–32 m/sec depending on model). Proven chemical savings through accurate delivery via 5-mode controller. Spray efficiency increases with micron-level droplet size. Operating cost optimized through fuel-efficient design and water savings.
- Farmer Decision Support
Farm Size Recommendations
- Small farms (under 5 acres): Bullet 3PL—compact design, lowest turning radius
- Medium farms (5–25 acres): Bullet 575 or 616—enhanced air output
- Low-spacing vineyards: Bullet 3PL—specially designed for constrained turning radius
Crop-Specific Recommendations
- Grapes: Grapemaster Bullet—optimized for vineyard applications
- Pomegranates: Pomemaster Rocket—designed for pomegranate orchards
- Oranges: Orangemaster Bullet—citrus orchard specialist
- General Orchards: Bullet 575 or 616 for balanced performance
Budget-Wise Categorization
- Economy Model: Bullet 3PL—18 HP tractors, cost-effective
- Mid-Range: Bullet 575—enhanced fan size and air output
- Premium: Bullet 616—maximum air output (32 m/sec) and pump capacity (65 LPM)
ROI & Financing
Payback within one season through proven chemical savings, labor savings, and water savings (90%). Government subsidies available. Loan facilities available with attractive interest rates. Affordable pricing compared to other sprayers in the market.
- Maintenance and Care of Mitra Bullet
- Pump Maintenance: Inspect diaphragm regularly; replace worn components as needed; protected by automatic pressure relief valve (40 bar)
- Nozzle Care: Clean high-quality brass nozzles after each use; calibrate monthly
- Tank Cleaning: Flush 200L tank thoroughly after each application; monitor water level via rear-side indicator
- Air Conveyor System: Inspect stainless steel shell, fins, backplate, bottom baffle, inlet vanes, and deflectors; adjust air recovery duct
- Gearbox: Check 2-speed + 1 neutral gearbox; use neutral during flowering stage
- Filtration System: Clean suction filter (primary) and brass line filter (secondary) regularly
- Safety Devices: Inspect pressure relief valve and rear bumper protection
- Agitator: Check mechanical agitator for constant chemical concentration
- Basket Mixture: Clean basket mixture used for dry powder mixing
- Seasonal Storage: Drain tank; clean all components; store in dry area
- Pre-Operation Checklist: Verify PTO shaft connection, gearbox setting, controller mode, nozzle spray patterns
- Longevity Factors of Mitra Bullet
Stainless steel air conveyor system (shell, fins, backplate) resists corrosion. High-quality brass nozzles ensure wear resistance. HDPE tank with water level indicator provides durability. Safety devices (pressure relief valve, rear bumper) protect components. 2-speed gearbox reduces wear during delicate operations. Expected service life of 8–10 years with proper maintenance and doorstep service support.
FAQs
What tractor horsepower is required for Mitra Bullet sprayer?
18 HP and above for Bullet 3PL; 24 HP and above for Bullet 575 and 616. Bullet 3PL recommended for 28 HP tractors but can be used on 18 HP and above with customized mounting plates.
What types of sprayers are available in Mitra Bullet, and what are their applications?
Air-assisted sprayers with rear air conveyor available in three variants (Bullet 3PL, 575, 616) for orchard and vineyard applications including grapes, pomegranates, oranges, mangoes, guava, custard apples for pest control, disease prevention, and multipurpose spraying and dipping applications.
What is the tank capacity and fan size of the Mitra Bullet sprayer?
Tank capacity: 200 L (compact for constrained turning radius); Fan sizes: 550 mm (3PL), 575 mm (575), 616 mm (616).
How does Mitra Bullet sprayer help in crop protection and pest management?
Delivers perfect air balancing with highest air output (24–32 m/sec) and low power consumption, breaking water droplets into thousands of microns for uniform coverage, effective pest control, disease prevention, and proven chemical savings with accurate delivery via 5-mode manual controller.
Why is pump quality and nozzle type important in Mitra Bullet sprayer?
Quality diaphragm pump (55–65 LPM) protected by automatic pressure relief valve (40 bar) ensures consistent pressure; high-quality brass nozzles with two-way design ensure precise spray patterns, micron-level droplet size, and wear resistance for long service life.
Is Mitra Bullet sprayer compatible with all tractor brands and models in India?
Yes, fits 3-point linkage (Bullet 3PL) or customized mounting plates on tractors ≥ 18 HP, compatible with Mahindra, Kubota, and other major brands. Specially designed mounting plates ensure compatibility across brands.
What about height adjustment and spray pressure control in Mitra Bullet sprayer?
Bullet 3PL offers hydraulic height adjustment for muddy conditions and grape canopy height; automatic pressure relief valve opens at 40 bar to protect pump; 5-mode manual controller provides accurate chemical delivery control; 2-speed + 1 neutral gearbox allows low-speed operation during flowering.
How does Mitra Bullet sprayer compare to other crop protection methods?
Offers 90% water savings (10 times less consumption), proven chemical savings, proven labor savings, uniform coverage, best crop protection, faster application (5–7 ha/day), and lowest turning radius for constrained vineyards compared to conventional or manual spraying methods.
What maintenance schedule should be followed for Mitra Bullet sprayer?
Regular inspection of diaphragm pump, brass nozzles, filtration system (suction and brass line filters), stainless steel air conveyor components, gearbox, agitator, and safety devices; clean basket mixture and tank after each use; seasonal comprehensive maintenance with doorstep service available.
What warranty and after-sales service support is available for Mitra Bullet?
1 year warranty with doorstep service support; pan-India dealer network; loan facilities available with attractive interest rates; government subsidies available; affordable pricing; safety devices included (pressure relief valve, rear bumper).
TractorXpert helps farmers choose the right sprayer implement by comparing models, prices, features, and benefits from different manufacturers, helping them save money, improve crop protection efficiency, reduce chemical wastage, and enhance overall farm productivity through precise and effective spraying solutions that enable farmers to protect their crops from pests, diseases, and weeds while optimizing chemical usage and ensuring uniform coverage across their fields for maximum agricultural yield and profitability.
