Krishi Spray KX 200, KX 400, KX 600
{{ galleryProps.activeIndex + 1 }}/3
Description
- About Product
| Specification | KX 200 | KX 400 | KX 600 |
| Brand | …
- About Product
| Specification | KX 200 | KX 400 | KX 600 |
| Brand | Krishi Spray | Krishi Spray | Krishi Spray |
| Model Name | KX 200 | KX 400 | KX 600 |
| Implement Type | Boom Sprayer | Boom Sprayer | Boom Sprayer |
| Category | Crop Protection | Crop Protection | Crop Protection |
| Compatible Tractor Power | 24+ HP | 35+ HP | 35+ HP |
| Price Range | ₹1,80,000* – ₹3,50,000* | ₹1,80,000* – ₹3,50,000* | ₹1,80,000* – ₹3,50,000* |
- Key Specification and Technology Krishi Spray KX Series
| Parameter | KX 200 | KX 400 | KX 600 |
| Sprayer Type | Boom sprayer | Boom sprayer | Boom sprayer |
| Tank Capacity | 200 liters | 400 liters (3-phase with circuit cleaning & hand wash tank) | 600 liters (3-phase with circuit cleaning & hand wash tank) |
| Pump Type | 60 LPM Diaphragm Pump | 60 LPM Diaphragm Pump | 60 LPM Diaphragm Pump |
| Pump Capacity | 60 liters per minute | 60 liters per minute | 60 liters per minute |
| Maximum Working Pressure | 40 bar maximum | 40 bar maximum | 40 bar maximum |
| Boom Width | 6 meters (20 feet) | 10 meters (32 feet) | 10 meters (32 feet) |
| Number of Nozzles | 12 Italian nozzles | 20 Italian nozzles | 20 Italian nozzles |
| Nozzle Spacing | 50 cm standard | 50 cm standard | 50 cm standard |
| Nozzle Types | Albuz Ceramic (ATR Hollow Cone or AXI flat fan) | Albuz Ceramic (ATR Hollow Cone or AXI flat fan) | Albuz Ceramic (ATR Hollow Cone or AXI flat fan) |
| Overall Dimensions | Compact mounted design | Medium mounted design | Large mounted design |
| Weight | Lightweight construction | Medium weight | Heavy-duty construction |
| Tractor Power | 24+ HP | 35+ HP | 35+ HP |
| Mounting Type | 3-point linkage | 3-point linkage | 3-point linkage |
| Drive System | PTO driven | PTO driven | PTO driven |
| PTO Speed | 540 RPM | 540 RPM | 540 RPM |
| Tank Material | High-grade aluminum mold | High-grade aluminum mold | High-grade aluminum mold |
- Technical Specifications Krishi Spray KX Series
| Technical Parameter | KX 200 | KX 400 | KX 600 |
| Application Rate Capacity | 150-300 L/ha | 200-400 L/ha | 250-500 L/ha |
| Field Coverage Efficiency | 1.0-1.8 ha/hr | 1.5-2.5 ha/hr | 2.0-3.0 ha/hr |
| Boom Height Adjustment | Manual adjustment | Manual adjustment | Manual adjustment |
| Pump Working Pressure | Up to 40 bar | Up to 40 bar | Up to 40 bar |
| Agitation System | Braglia Tank mixers | Braglia Tank mixers | Braglia Tank mixers |
| Filtration System | Suction filters | Suction filters | Suction filters |
| Control System | HD-6 Controller (3-way/4-way) | HD-6 Controller (3-way/4-way) | HD-6 Controller (3-way/4-way) |
| Operating Speed Range | 4-8 km/hr | 4-8 km/hr | 4-8 km/hr |
| Chemical Compatibility | Pesticides, fungicides, herbicides | Pesticides, fungicides, herbicides | Pesticides, fungicides, herbicides |
| Weather Suitability | Standard field conditions | Standard field conditions | Standard field conditions |
| Maintenance Intervals | Regular pump and filter checks | Regular pump and filter checks | Regular pump and filter checks |
| Spare Parts Availability | Available through dealers | Available through dealers | Available through dealers |
| Warranty Coverage | Standard manufacturer warranty | Standard manufacturer warranty | Standard manufacturer warranty |
- Agricultural Benefits and Applications of Krishi Spray KX Series
Primary Crop Protection Applications: The KX series delivers comprehensive pest control, disease prevention, and weed management solutions for ground crops including soybean, tur, chilli, cotton, rice, sugarcane, cereals, and pulses. Each variant provides precise chemical application tailored to specific farm sizes and crop requirements.
Precision Spraying Benefits: Italian nozzles with Albuz ceramic tips create optimal droplet size for maximum penetration while minimizing chemical wastage. The 60 LPM diaphragm pump ensures consistent flow rate with pressure capability up to 40 bar for precision application across all variants.
Multi-crop Compatibility: Designed for diverse ground crop applications with boom widths ranging from 6-10 meters to accommodate different field sizes and crop configurations. The ceramic spray tips offer both hollow cone and flat fan options for various application requirements.
Resistance Management: Supports integrated pest management programs with precise chemical application and uniform coverage patterns that help prevent resistance development in pest populations while ensuring effective control across multiple crop types.
- Enhanced Farming Efficiency through Krishi Spray KX Series
Time-saving Benefits: KX 200 covers 1.0-1.8 ha/hr, KX 400 covers 1.5-2.5 ha/hr, and KX 600 covers 2.0-3.0 ha/hr, significantly reducing application time compared to manual methods. Large tank capacities minimize refilling frequency and maximize operational efficiency.
Chemical Cost Reduction: Precision application through Italian nozzles and ceramic tips minimize chemical wastage through accurate droplet formation. The diaphragm pump maintains consistent chemical mixing throughout operation with efficient agitation systems.
Labor Efficiency Improvements: Single operator can manage spraying operations with PTO-driven system and HD-6 controller for precise operation control. The 3-point linkage design ensures easy attachment and operation across different tractor models.
Increased Application Accuracy: Italian nozzles with 50cm spacing deliver uniform spray distribution across boom widths ranging from 6-10 meters. The diaphragm pump ensures consistent pressure and flow rate for optimal chemical application.
Reduced Environmental Impact: Controlled droplet size and boom spray technology minimize spray drift while ensuring effective crop protection. The system optimizes chemical usage and reduces environmental contamination through precise application.
- Versatile Crop Applications through Krishi Spray KX Series
Field Crops: Specially designed for soybean, tur, chilli, cotton, rice, sugarcane, cereals, and pulses with boom widths that accommodate standard row spacing and provide uniform coverage across crop types.
Ground Crop Specialization: Ideal for potato (KX 600), soybean, cotton, rice, and other ground crops requiring uniform spray coverage and precise chemical application for effective pest and disease control.
Row Crop Applications: Suitable for various row crops with boom configurations that provide comprehensive coverage while minimizing crop damage through controlled boom height and nozzle positioning.
Cereal and Pulse Crops: Effective for wheat, rice, and pulse crops with boom widths that cover multiple rows simultaneously for efficient field operations and uniform chemical distribution.
Cash Crop Protection: Cotton, sugarcane, and other high-value crops benefit from precise application and uniform coverage provided by the ceramic nozzle system and controlled pressure application.
- Performance Specifications of Krishi Spray KX Series
Application Precision: Italian nozzles with Albuz ceramic tips ensure consistent spray quality and uniform droplet distribution across all variants. The 60 LPM diaphragm pump provides reliable flow rate with 40 bar maximum pressure capability for precise application control.
Coverage Efficiency Ratings: KX 200 achieves 70-75% field efficiency, KX 400 reaches 75-80%, and KX 600 achieves 80-85% efficiency under normal operating conditions. Coverage rates vary based on boom width and operating speed.
Spray Drift Control: Boom spray technology with controlled droplet size minimizes spray drift while maintaining penetration effectiveness. Operating parameters optimized for ground crop requirements and field conditions.
Chemical Utilization Efficiency: Diaphragm pump system with tank mixers ensures consistent chemical mixing and application with rates ranging from 150-500 L/ha depending on crop requirements and variant specifications.
Operating Cost Analysis: PTO-driven operation eliminates separate engine costs while fuel consumption averages 4-6 L/hr depending on tractor efficiency and operating conditions across all variants.
- Farmer Decision Support
Farm Size Recommendations:
- Small farms (5-10 acres): KX 200 with 200L capacity and 6-meter boom ideal for compact operations
- Medium farms (10-25 acres): KX 400 with 400L capacity and 10-meter boom for balanced coverage and efficiency
- Large farms (25+ acres): KX 600 with 600L capacity and 10-meter boom for extensive coverage and minimal refilling
Crop-specific Recommendations:
- Row crop applications: All variants suitable with boom widths accommodating standard row spacing
- Ground crop specialization: KX series designed specifically for ground crops with appropriate boom heights
- Multi-crop flexibility: Ceramic nozzle options provide versatility for different chemical applications
Budget-wise Categorization:
- Economy option: KX 200 at ₹1,80,000* – ₹2,20,000* for small-scale operations
- Mid-range choice: KX 400 at ₹2,30,000* – ₹2,80,000* for medium-scale farming
- Premium investment: KX 600 at ₹2,80,000* – ₹3,50,000* for large-scale operations
ROI Calculation Guidance: Payback period typically 2-3 seasons based on chemical savings, labor reduction, and increased application efficiency across all variants.
Financing Options: Available through agricultural equipment loans and government subsidy programs for mechanization.
- Maintenance and Care of Krishi Spray KX Series
Pump Maintenance: 60 LPM diaphragm pump requires regular inspection and maintenance according to manufacturer specifications. Check pump seals, pressure relief valve, and flow rate calibration for optimal performance with 40 bar pressure capability.
Nozzle Care and Calibration: Italian nozzles with Albuz ceramic tips require periodic cleaning and calibration to maintain precise spray patterns. Ceramic tips offer superior wear resistance compared to standard materials for extended service life.
Tank and Agitation System: High-grade aluminum tanks require minimal maintenance with periodic cleaning and inspection. Braglia tank mixers ensure proper chemical agitation and should be checked regularly for optimal mixing performance.
Boom Maintenance: Manual boom systems require periodic inspection for proper alignment and structural integrity. Lubricate adjustment points regularly and check boom folding mechanisms for smooth operation.
Control System Care: HD-6 controller with 3-way/4-way options requires regular inspection and calibration. Clean electrical connections and check control functions periodically for reliable performance.
Filtration System Maintenance: Suction filters require regular cleaning and replacement to prevent clogging and maintain spray quality. Follow manufacturer recommendations for filter replacement schedules.
Pre-operation Inspection: Daily checks of pump pressure, nozzle function, boom alignment, and control system ensure safe and efficient operation throughout the spraying season.
- Longevity Factors of Krishi Spray KX Series
Component Quality: 60 LPM diaphragm pump and Italian nozzles provide superior durability and performance compared to standard components. Hot-dip galvanized chassis ensures corrosion resistance and structural integrity.
Chemical Resistance Features: High-grade aluminum tanks and galvanized components provide excellent chemical compatibility and corrosion resistance for agricultural chemical exposure. Ceramic nozzle tips offer superior wear resistance.
Structural Engineering: Robust 3-point linkage design withstands field operating conditions while maintaining compatibility with various tractor types. Quality construction ensures stable operation across diverse terrain conditions.
Wear Part Replaceability: Standard Italian components including nozzles, pump parts, and control elements are readily available through dealer networks. Modular design facilitates maintenance and component replacement.
Expected Service Life: Properly maintained units typically provide 8-12 years of reliable service with regular component replacement. Quality construction and materials ensure long-term durability in demanding agricultural environments.
FAQs Section
What tractor horsepower (HP) is required for Krishi Spray KX series sprayers?
KX 200 requires 24+ HP tractors, while KX 400 and KX 600 require 35+ HP tractors with 540 RPM PTO capability and standard 3-point linkage system for optimal performance.
What types of sprayers are available in Krishi Spray KX series, and what are their applications?
All KX models are boom sprayers designed for ground crops. KX 200 has 6-meter boom for small farms, while KX 400 and KX 600 feature 10-meter booms for larger operations with ground crops like soybean, cotton, rice, and cereals.
What is the tank capacity and boom width of the Krishi Spray KX series sprayers?
KX 200 has 200L tank with 6-meter boom, KX 400 has 400L tank with 10-meter boom, and KX 600 has 600L tank with 10-meter boom. All feature 3-phase tanks with circuit cleaning capabilities.
How do Krishi Spray KX series sprayers help in crop protection and pest management?
The sprayers deliver precise chemical application through Italian nozzles with ceramic tips and 60 LPM diaphragm pump for comprehensive pest, disease, and weed control across various ground crops.
Why is pump quality and nozzle type important in Krishi Spray KX series sprayers?
The 60 LPM diaphragm pump provides consistent flow with 40 bar pressure capability, while Italian nozzles with Albuz ceramic tips ensure precise spray patterns and superior wear resistance for long-term reliability.
Are Krishi Spray KX series sprayers compatible with all tractor brands and models in India?
Yes, all KX models are compatible with tractors having appropriate HP power, 540 RPM PTO, and standard 3-point linkage system, covering most Indian tractor brands and models.
What about boom height adjustment and spray pressure control in Krishi Spray KX series sprayers?
All models feature manual boom height adjustment and HD-6 controller with 3-way/4-way options for precise operation control and pressure management up to 40 bar.
How do Krishi Spray KX series sprayers compare to other crop protection methods?
KX series provides coverage efficiency of 1.0-3.0 ha/hr compared to 0.2-0.4 ha/hr for manual spraying, with better chemical utilization and uniform coverage for ground crops.
What maintenance schedule should be followed for Krishi Spray KX series sprayers?
Regular maintenance includes daily nozzle cleaning, weekly pump inspection, monthly filter replacement, and seasonal comprehensive maintenance of all Italian components and boom systems.
What warranty and after-sales service support is available for Krishi Spray KX series?
Krishi Spray provides standard manufacturer warranty with authorized dealer network support. Italian component parts and service support ensure reliable long-term operation and maintenance.
TractorXpert helps farmers choose the right sprayer implement by comparing models, prices*, features, and benefits from different manufacturers, helping them save money, improve crop protection efficiency, reduce chemical wastage, and enhance overall farm productivity through precise and effective spraying solutions that enable farmers to protect their crops from pests, diseases, and weeds while optimizing chemical usage and ensuring uniform coverage across their fields for maximum agricultural yield and profitability.
