Boraste Agro (ADITI) Low Volume Sprayer
{{ galleryProps.activeIndex + 1 }}/1
Description
- About Product
| Attribute | Details |
| Brand | Boraste Agro (ADITI) |
- About Product
| Attribute | Details |
| Brand | Boraste Agro (ADITI) |
| Model Name | Low Volume Sprayer |
| Implement Type | Orchard Sprayer / Air Blast Sprayer |
| Category | Crop Protection / Plant Protection |
| Compatible Tractor Power | 18–24 HP and above |
| Price Range* | ₹65,000* to ₹95,000* |
- Key Specification and Technology – Low Volume Sprayer
| Specification | Details |
| Sprayer Type | Low Volume Air-Assisted Sprayer |
| Tank Capacity | 100–200 L |
| Pump Type | Diaphragm Pump |
| Pump Capacity | 35–50 LPM |
| Maximum Working Pressure | 20–30 bar |
| Application Volume | 50–150 L/ha (Low Volume Range) |
| Fan Size | 500–600 mm |
| Fan Type | Adjustable Aluminium Axial Fan |
| Number of Nozzles | 6–10 |
| Nozzle Spacing | Variable spacing |
| Nozzle Types | Adjustable Cone / Hollow Cone |
| Overall Dimensions (L×W×H) | 1,200 × 1,000 × 1,300 mm |
| Weight (Unladen) | 80–120 kg |
| Tractor Power Requirement | 18 HP and above |
| Mounting Type | 3-Point Linkage |
| Drive System | PTO Driven |
| PTO Speed Requirement | 540 RPM Standard |
| Tank Material | High-Density Polyethylene (HDPE) |
| Chassis | Spray Painted / Powder Coated |
- Technical Specifications – Low Volume Sprayer
| Parameter | Specification |
| Application Rate Capacity | 50–150 L/ha (Low Volume) |
| Field Coverage Efficiency | Up to 4–6 ha/day |
| Fan Height Adjustment | Height Adjustable Fan Unit |
| Pump Working Pressure | 3–8 bar Recommended |
| Agitation System | Jet Agitation |
| Filtration System | Suction Filter, Inline Filter |
| Control System | Manual Valve Control System |
| Operating Speed Range | 3–6 km/hr |
| Chemical Compatibility | Pesticides, Fungicides, Insecticides (Concentrated) |
| Weather Suitability | Wind 3–10 km/hr, Temperature 5–35 °C |
| Maintenance Intervals | Every 100 hrs or season |
| Spare Parts Availability | Pan-India Dealer Network |
| Warranty & Service Support | 1 Year Manufacturer Warranty, Doorstep Service |
| Water Savings | Up to 70% compared to high-volume sprayers |
- Agricultural Benefits and Applications of Low Volume Sprayer
The Boraste ADITI Low Volume Sprayer delivers concentrated pesticide application with minimal water usage for effective pest control, disease prevention, and fungicide application in orchards. The low-volume technique (50–150 L/ha) ensures maximum chemical efficiency with reduced drift and improved penetration into crop canopy.
- Enhanced Farming Efficiency through Low Volume Sprayer
This sprayer covers up to 4–6 hectares daily while using 70% less water than conventional high-volume sprayers. Concentrated chemical application reduces wastage and ensures 25–30% labor cost reduction. Quick refilling and lighter equipment weight enable faster operation and reduced operator fatigue.
- Versatile Crop Applications through Low Volume Sprayer
Horticultural Crops: Grapes, pomegranates, oranges, mangoes, guava
Orchard Crops: Apple, lychee, custard apple
Row Crops: Cotton, soybean, groundnut
Special Applications: Fungicide application, insecticide spraying, concentrated pest control in dry-land areas where water is scarce
- Performance Specifications of Low Volume Sprayer
Achieves 90–92% spray uniformity with concentrated chemical droplets. 85% chemical utilization efficiency minimizes wastage. Low-volume application (50–150 L/ha) ensures reduced application time, water savings, and operating cost under ₹100*/ha. Ideal for water-scarce regions and precision agriculture.
- Farmer Decision Support
Farm Size Recommendations
- Small farms (under 5 acres): Low Volume Sprayer—ideal for compact orchards
- Medium farms (5–25 acres): Combine with standard capacity models
- Dry-land areas: Perfect solution where water availability is limited
Crop-Specific Recommendations
- Grapes & Pomegranates: Concentrated fungicide application
- Orchards with Water Scarcity: Low-volume technique saves water
- Cotton & Soybean: Quick pest control with minimal water
- Home Gardens & Small Fields: Ideal for limited area spraying
Budget-Wise Categorization
- Economy Model: Low Volume Sprayer—most affordable, water-saving solution
- Mid-Range: Combine with air-assisted features for better coverage
- Premium: Upgrade to ECO series for larger capacity
ROI & Financing
Payback within one season through water savings (70%), chemical efficiency (25% savings), and labor reduction (30%). FMTIC Tested & Approved quality. Government subsidies available under agricultural mechanization schemes.
- Maintenance and Care of Low Volume Sprayer
- Pump Maintenance: Inspect diaphragm every 50 hrs; replace worn components annually
- Nozzle Care: Clean adjustable cone nozzles after each use; calibrate monthly
- Tank Cleaning: Flush tank thoroughly after each application; avoid chemical residue buildup
- Fan Maintenance: Check fan blades; adjust angles as needed; lubricate moving parts
- Filtration System: Clean suction and inline filters weekly
- Regular Maintenance: Clean, oil, and grease components every 8–15 days
- Seasonal Storage: Drain tank completely; clean all components; store in dry area
- Pre-Operation Checklist: Verify PTO connection, fan operation, nozzle spray patterns, pressure settings
- Longevity Factors of Low Volume Sprayer
HDPE tank resists chemical corrosion and UV degradation. Spray-painted/powder-coated chassis provides basic corrosion protection. Adjustable cone nozzles designed for concentrated applications ensure longevity. Lightweight design reduces wear on tractor components. FMTIC tested quality standards guarantee a 6–8 year service life with proper maintenance.
FAQs
What tractor horsepower is required for Low Volume Sprayer?
18 HP and above.
What types of sprayers are available in Low Volume Sprayer, and what are their applications?
Low-volume air-assisted sprayer for orchard and field crop spraying using concentrated chemical applications (50–150 L/ha) ideal for water-scarce areas, pest control, and fungicide application in grapes, pomegranates, cotton, and other crops.
What is the tank capacity and application volume of the Low Volume Sprayer?
Tank capacity: 100–200 L; Application volume: 50–150 L/ha (Low Volume technique).
How does Low Volume Sprayer help in crop protection and pest management?
Delivers concentrated pesticide application with minimal water usage, ensuring effective pest control, disease prevention, and fungicide application while saving up to 70% water compared to high-volume sprayers.
Why is pump quality and nozzle type important in Low Volume Sprayer?
Quality diaphragm pump (35–50 LPM) maintains consistent pressure for concentrated application; adjustable cone and hollow cone nozzles ensure proper atomization and uniform coverage with minimal water.
Is Low Volume Sprayer compatible with all tractor brands and models in India?
Yes, fits standard 3-point linkage and PTO shafts (540 RPM) on tractors ≥ 18 HP, compatible with Mahindra, John Deere, Sonalika, Swaraj, Farmtrac, and other brands.
What about fan height adjustment and spray pressure control in Low Volume Sprayer?
Height-adjustable fan unit allows vertical positioning; manual valve control system provides pressure adjustment (3–8 bar operating range); adjustable nozzles enable droplet size control.
How does Low Volume Sprayer compare to other crop protection methods?
Offers 70% water savings, faster application (4–6 ha/day), 25% labor cost reduction, reduced chemical wastage, and suitability for water-scarce regions compared to high-volume spraying methods.
What maintenance schedule should be followed for Low Volume Sprayer?
Cleaning, oiling, and greasing every 8–15 days; diaphragm inspection every 50 hrs; nozzle and filter cleaning after each use; fan and pump inspection quarterly; annual component replacement as needed.
What warranty and after-sales service support is available for Low Volume Sprayer?
1 year manufacturer warranty with PAN India service network providing doorstep installation and after-sales support; FMTIC tested quality; spare parts readily available through authorized dealers.
TractorXpert helps farmers choose the right sprayer implement by comparing models, prices, features, and benefits from different manufacturers, helping them save money, improve crop protection efficiency, reduce chemical wastage, and enhance overall farm productivity through precise and effective spraying solutions that enable farmers to protect their crops from pests, diseases, and weeds while optimizing chemical usage and ensuring uniform coverage across their fields for maximum agricultural yield and profitability.
